UHMWPE board outrigger pad specifications crane outrigger pads

Pulished on Mar. 19, 2022

The outrigger pad of the crane is composed of two parts: the plate body and the hand rope. The plate body is made of UHMWPE composite material through a special process of high temperature and high pressure. The portable rope is made of nylon material. The end of the movable rope board is embedded in the board body for easy carrying and arrangement.

Thinckness	Size	Load Capacity(TONS)		Weight
MM	MM	45°	Vertical	KGS
25MM	500*500	30	55	6.25
	600*600	35	60	9
	800*800	40	81	16
	1000*1000	43	93	25
	1200*1200	50	130	36
	Dia.800	38	78	12.5
	Dia.1000	41	91	20
	Dia.1200	48	110	28
40mm	500*500	31	56	10
	600*600	36	61	14.4
	800*800	42	82	25.6
	1000*1000	44	94	40
	1200*1200	51	131	57.6
	Dia.800	40	80	20
	Dia.1000	42	92	32
	Dia.1200	48	130	45
50mm	500*500	31	58	12.5
	600*600	40	62	18
	800*800	43	85	32
	1000*1000	45	98	50
	1200*1200	55	140	72
	Dia.800	41	83	25
	Dia.1000	43	95	40
	Dia.1200	52	137	56
60mm	800*800	43	86	38.4
	1000*1000	45	99	60
	1000*1000	53	133	86.4
	Dia.800	41	84	30
	Dia.1000	42	96	48

Outrigger pads feature：
1. It can be easily rinsed with clean water, and the zero water absorption rate will never break, ensuring clean and safe use.
2. Strong corrosion resistance.
3. Can be used in extreme weather conditions (-180°C to +80°C)
4. Make sure the pad is safe and stable in the center of the outrigger/outrigger foot position/slot
5. Protect the environment: the backing board can be recycled, no air pollution, and avoid frequent replacement of wood
6. The water absorption rate is low, and the external dimensions will not be changed due to the humid environment.
7. Ensure the safety of the outriggers;
8. From the customization of cost-benefit standards to ensure your accounting costs
9. We provide the best quality and service guarantee
