4x8 Ground Protection Mats
Temporary works are often particularly slippery due to rain and snow, posing potential hazards to passing pedestrians and vehicles. In addition, under the action of repeated rolling of the steel paving steel plate, the end of the plate will warp and deform. In this way, when passing vehicles are driving, it will not only bring noise pollution to the city, but also cause major safety hazards to pedestrians and vehicles, and correspondingly reduce the service life of the steel support plate.
4x8 ground protection mats have now replaced steel plates and boards and can be used as temporary roads to avoid damage to lawns or roads, effectively improving work efficiency and reducing the impact of on-site construction. On sandy, muddy swamps, and snow, it can be placed under the wheels to increase friction.
Ground Production Mats Standard Size
| Item.No | Size(mm) | Weight(kg) | Effective area(m2) | Loading capacity(ton) | Loading container &calculate |
| XE01 | 2000*1000*10mm | 22.6kg | 2m2 | 30ton | 590pcs in 20'GP 1150pcs in 40'GP |
| XE02 | 2400*1200*12.7mm | 40kg | 2.88m2 | 40ton | 320pcs in 20'GP 580pcs in 40'GP |
| XE03 | 2440*1220*12.7mm | 42kg | 2.98m2 | 40ton | 300pcs in 20'GP 550pcs in 40'GP |
| XE04 | 2900*1100*12.7mm | 45kg | 3.2m2 | 40ton | 350pcs in 20'GP 580pcs in 40'GP |
| XE05 | 3000*1500*15mm | 74kg | 4.5m2 | 80ton | 320pcs in 40'GP |
| Remark: *Material :Virgin HDPE (High density polyethylene) *For wheeled vehicle *Recommend thickness :10mm,12.7mm,15mm,18mm,20mm, 25mm,40mm *Color:White, yelllow,black ,red,blue and etc | |||||
Our ground mats patterns
We have three connectors for connecting the ground mats into a plane.
Our ground mats connectors
Characteristics for HDPE ground mats
1. Light weight, easy to install, and can be moved at will.
2. It will not rust or rot, and it is easy to clean.
3. Long service life, can be used repeatedly.
4. Small contact damage to tires, etc.
5. The use cost is low and economical.
Our ground mats package
