Wear strips and components are often made of plastic, which provides protection from surface marring and scratching, noise reduction between mating parts, and elimination of slipping and sticking amid sliding parts. One of the most common plastic materials used in wear strip applications is UHMW (Ultra High Molecular Weight Polyethylene). UHMW’s unique properties including high impact/abrasion resistance, self-lubrication, long wear life and ease of machining make it ideal for this application. Wear strips and components are resistant to corrosion and chemicals and able to keep moving parts free of external grease and lubricants. Wear strips and components are commonly used with bearings, slides, gears, cams, bushings, and rollers.
white wear strip with CNC process
High chemical resistance, fatigue resistance, noise damping resistance, radiation resistance. Use temperature 100--110 ℃. It has outstanding impact resistance, resistance to stress cracking, high temperature creep resistance, low coefficient of friction, self-lubricating. Can use at -269 ℃. Density 0.985g / cm3 molecular weight of 2,000,000 of product, its tensile strength of 40MPa crack crack elongation of 350%, the elastic modulus of 600MPa tortuous Izod notched impact punch continued. The amount of wear (MPC method) 20mm.
Features and Benefits of AABOSN uhmwpe Adhesive Wear Strip:
No more seams
Tight thickness tolerances
Elimination of waste
Quick and easy application
Can be applied in minutes rather than several hours
Available in convenient rolls which can be cut to size as needed
Removes the need for mechanical fastening
UHMWPE wear resistant strip Applications
1,Used as lining board for bunker,chute,mixer,warehouse etc selflubrication and wear resisting needed areas
2,Made into block,dock fender board etc special purpose and special shaped products.
3,Made into all kinds of mechanical parts according to drawings under the help of lathe,mill machine and mould.
4,Due to the excellent property of high intensity and impact resisting,UHMWPE boards have been used in military include pallet for bulletproof jacket and bulletproof shield ,Protection level III and IV .
5,Other fields include Ice rink,water tank etc
