Polymer containing boron anti radiation protection Waterproof Plastic Anti-static Boron added UHMWPE Sheet
The boron-containing polyethylene plate produced by our company is a new type of composite shielding material made by high temperature molding molding process, through rapid stirring, kneading, plasticizing, enhancing the bonding force between boron carbide B4C and UHMWPE, and then high temperature and high pressure.
Thickness: 15cm 10% boron carbide polyethylene technical index: (10% by weight)
Density: ≥1.028g/cm3 Density difference: ≤0.01g/cm3
Linear expansion coefficient: 8.933×10-51/℃ Heat resistance temperature: 126℃ (DTA measurement value)
Compressive strength: ≈24MPa Impact strength (notch) : ≈19KJ/m2
Thermal deformation temperature (load ρ=0.46Mρa) : 72℃
Mainly used for neutron protection and γ-rays, with good radiation resistance, no activated products, low energy secondary γ-rays, high mechanical properties, corrosion resistance, non-toxic tasteless, impact resistance, low temperature resistance and chemical stability.
According to customer requirements to add boron carbide, borax, boron trioxide, lead powder, lithium carbonate, etc., content of 3%-30% can be customized production, and according to your drawings or requirements of CNC plus finished products!
Boron UHMWPE sheet standard size:
3000X1500X(10-260)MM 3050X1220X(10-260)MM
4700X1200X(10-260)MM 5000X1300X(10-260)MM
4500X2000X(10-260)MM 2000X1000X(10-260)MM
6000X1800X(10-260)MM 3000X3000X(10-260)MM
Boron-containing polyethylene plate is mainly used in the research fields of nuclear power plant, nuclear reactor, CNPC, military, Chinese Academy of Sciences, research office, hospital and nuclear experimental product tank, neutron beam collimator, neutron trap and nuclear reactor control rod material and nuclear shielding material. As a material to shield neutrons, rays and radiation from absorption.
