High Density Polyethylene Outrigger Pads 600x600 Easy Handled Hdpe Outrigger Pad

Share:
Product details

UHMWPE Crane Boom Wear Pads Outrigger Crane Mats

Composite UHMWPE  crane outrigger pads made from UHMWPE (ultra high molecular weight polyethylene) and

are significantly more durable and lighter than traditional wood or steel pads.

Wood outrigger pads tend to splinter, hold water, and rot overtime.

Steel and aluminum pads tend to corrode, discolor, warp, and are heavy .

Wear Resistant UHMWPE Crane Foot Support Pad Outrigger Pad

Wear Resistant UHMWPE Crane Foot Support Pad Outrigger Pad



We are pleased to say we are now able to offer the additional service of stamping each outrigger pad with your Company Name,

Vehicle Registration Number, Telephone Number etc.

Maximum of three lines per pad.

Good discounts given for bulk orders.

Thickness(inch)

Pad size(inch)

Part Number

45° Load

Vertical Load

Pad Weight

1”Square

18×18

X1T1818

14 tonnes

25 tonnes

5.00kgs

1”rectangle

20×24

X1T2024

16 tonnes

27 tonnes

7.63kgs

1”Square

24×24

X1T2424

16 tonnes

34 tonnes

9.15kgs

1”Square

30×30

X1T3030

18 tonnes

36 tonnes

14.3kgs

1”Square

36×36

X1T3636

19 tonnes

42 tonnes

20.6kgs

1”Square

48×48

X1T4848

22.5 tonnes

59 tonnes

36.62kgs

1”Round

30”Dia

X1TR30

12 tonnes

28 tonnes

11.23kgs

1”Round

36”Dia

X1TR36

15 tonnes

32 tonnes

16.16kgs

1”Round

48”Dia

X1TR48

18 tonnes

45 tonnes

28.75kgs







1-2/1” Square

18×18

X1.5T1818

14 tonnes

25 tonnes

7.73kgs

1-2/1” Square

24×24

X1.5T2024

16 tonnes

27 tonnes

13.73kgs

1-2/1” Square

30×30

X1.5T3030

19 tonnes

37 tonnes

21.46kgs

1-2/1” Square

36×36

X1.5T3636

20 tonnes

43 tonnes

31.00kgs

1-2/1” Square

48×48

X1.5T4848

23 tonnes

59 tonnes

55.00kgs

1-2/1” Round

30”Dia

X.1.5TR30

14 tonnes

28 tonnes

16.85kgs

1-2/1” Round

36”Dia

X1.5TR36

15 tonnes

32 tonnes

24.24kgs

1-2/1” Round

48”Dia

X1.5TR48

18 tonnes

45 tonnes

43.13kgs







2”Square

18×18

X2T1818

14 tonnes

26 tonnes

10.30kgs

2”rectangle

20×24

X2T2024

18 tonnes

28 tonnes

15.26kgs

2”Square

24×24

X2T2424

18 tonnes

28 tonnes

18.31kgs

2”Square

30×30

X2T3030

19.5 tonnes

38 tonnes

28.62kgs

2”Square

36×36

X2T3636

20 tonnes

44 tonnes

41.20kgs

2”Square

48×48

X2T4848

25 tonnes

63 tonnes

73.25kgs

2”Round

30”Dia

X2TR30

15 tonnes

30 tonnes

22.47kgs

2”Round

36”Dia

X2TR36

16 tonnes

32 tonnes

32.33kgs

1”Round

48”Dia

X2TR48

19 tonnes

45 tonnes

57.51kgs







2-2/1” Square

24×24

X2.5T2424

17.5 tonnes

28 tonnes

22.89kgs

2-2/1” Square

30×30

X2.5T3030

19 tonnes

39 tonnes

35.76kgs

2-2/1” Square

36×36

X2.5T3636

20 tonnes

45 tonnes

51.50kgs

2-2/1” Square

48×48

X25T4848

24 tonnes

60 tonnes

91.56kgs

2-2/1” Round

30”Dia

X2.5TR30

15 tonnes

29 tonnes

28.09kgs

2-2/1” Round

36”Dia

X2.5TR36

15.3 tonnes

33 tonnes

40.41kgs

2-2/1” Round

48”Dia

X2.5TR48

19 tonnes

46 tonnes

71.88kgs







3” Square

24×24

X3T2424

18tonnes

29 tonnes

27.47kgs

3” Square

30×30

X3T3030

20 tonnes

40 tonnes

42.92kgs

3” Square

36×36

X3T3636

22 tonnes

47 tonnes

61.80kgs

3” Square

48×48

X3T4848

26 tonnes

66 tonnes

109.876kgs

3” Round

30”Dia

X3TR30

15 tonnes

30 tonnes

33.70kgs

3” Round

36”Dia

X3TR36

16 tonnes

36 tonnes

48.49kgs

3” Round

48”Dia

X3TR48

20 tonnes

51 tonnes

86.26kgs



Features of UHMWPE heavy crane outrigger pads :



--Highest abrasion resistance of any polymer, 6 times more abrasion resistant than steel

--Do not absorb moisture and will not swell up over time due to exposure outdoors.

--Good impact intensity,Do not lose their impact strength over time.

--Good breaking elongation,so they will bend but not break under extreme loads.

--Non-stick surface, easy to clean.

--Corrosion and chemical resistant.

--Noise- absorption, Vibration-absorption

--Super compression strength

--15 Percent the weight of steel pads and easier to handle

--Compressive loads up to one million pounds

--Up to 15,000 pounds per square foot

--Non-Conductive

--Non-Toxic and smell

Wear Resistant UHMWPE Crane Foot Support Pad Outrigger Pad
